Deck Over 10k-14k-16k

Product Details

Standard Equipment

• ST225/75R/15 LRE Tires on 6-Hole on 10K
• 5200# Dexter EZ-Lube 1/2 Cambered Elec.Brake Axles 10K
• ST235/80R/16 LRE Tires on 8-Hole on 14K
• 7000# Dexter EZ-Lube 1/2 Cambered Elec. Brake Axles 14K
• ST215/75R/17.5 LRH on 8-Hole on 16K
• 8000# Dexter Oil Bath 1/2 Cambered Elec. Brake Axles 16K
• 2 5/16" DEMCO Easy Latch Adjustable 5/Position Coupler
• 7000# Drop Leg Jack on 10K
• 10000# Drop Leg Jack on 14-16K
• Treated Pine Floor
• Break Away Unit w/Charger
• Spare Rack
• Color: Black

Frame Structure

• Frame/Tongue Integrated 8" x 10# I-Beam
• Crossmembers: 3" Channel 16" OC on 10K
• Crossmembers: 3" Channel 16" OC on 14K-16K
• Side Rails: 5x3x1/4
• Stake Pockets
• 3/8x2 Rubrail
• Expanded Metal Tray in Tongue

Options

• 10000# Drop Leg Jack (Standard on 14-16K)
• Adjustable Pintle Eye
• 6' Slide in Channel Ramps
• *4' Cleated Dovetail & 5' Slide-N-Channel Ramps
• *4' Cleated Dovetail & 5' Fold Up Channel Ramps w/Adjustable Knees
• *Optional Cleated Dovetail is part of existing length.
• ST235/80R/16 LRE Tire Upgrade (10K Only)
• 235/80R/16 LRE Tire Upgrade
• Spare ST225/75R/15 LRE on 6-Hole
• Spare ST235/80R/16 LRE on 8-Hole
• Spare ST215/75R/17.5 LRH on 8-Hole Black Mod

Model Table
