Lite Duty Utiltiy

Trailers - Trailers Tandem Axle / H.D. Utility / Landscaper

Print

Lite Duty Utiltiy

Trailers Tandem Axle / H.D. Utility / Landscaper

Brand: Top Hat
Inventory Status: Maintained in Inventory

Request More Info

Product Details

Standard Equipment

ST205/75R/15R LRC Tires
2-3500# Dexter EZ-Lube 1/2 Cambered Axles (LDT w/1-Electric)
2" Forged A-Frame Coupler
2000# Jack
9x72 Rolled Fenders
Treated Pine Floor
Stake Pockets
LED Lights
Color: Black Only

Frame Structure

Frame: 3x2x3/16
Toprail: 2" Square Tube 14GA
Crossmembers: 3x2x3/16
Tongue: 4" Channel
Uprights: 2x2x1/8
Square Cut Fender Braces Not Capped
No Board Brackets

Options

*Electric Brake 2nd Axle (3500#) (NA LDX)
Wrap Tongue
Set Back Jack
Spare Rack (Bolt on)
Spare ST205/75R/15 LRC on 5-Hole
Economy Production model. No Other Sizes or Options Available

Model Table

Model

Axle Description

Tire Size

GAWR

GVWR

12x77" LDX (No Brakes)

2 - 3500# Dexter

ST205/15 LRC Radial

GAWR: 2950#

GVWR: 4490#

14x77" LDX (No Brakes)

*No Brakes

16x77" LDX (No Brakes)

EZ Lube - 1/2 Cambered

12x77" LDT (w/Brakes)

2 - 3500# Dexter

ST205/15 LRC Radial

GAWR: 3500#

GVWR: 5000#

14x77" LDT (w/Brakes)

1 - Electric Brake Nev-R-Adjust

16x77" LDT (w/Brakes)

EZ Lube - 1/2 Cambered
