For impressive durability, great functionality and eye-catching design with zero tradeoffs, the AL ER model is the smart choice for your hauling needs. CM’s precision-engineered aluminum build is lighter weight yet ultra-strong, while delivering improved fuel economy and lasting corrosion-resistance.
Our headache racks are designed with the best and strongest materials, designed to set the standard when it comes to safety and protecting our customers.
(4) Standard Integrated Toolboxes with Lockable T-Handle Compression Latches
Our integrated, flush-mounted toolboxes feature adjustable T-Handle compression latches, providing a secure seal to protect your tools, straps, and chains from the elements.
4″ structural steel channel frame rails
Because we don’t use roll-formed runners, our structural 4″ channel frame rails are stronger and more durable than any on the market. They also prevent any rusting from the interior of the tube.
30,000 lb.-rated B&W gooseneck hitch with 7-way electrical plug
This is a best-in-class, independently tested gooseneck hitch that handles even your toughest hauls. It also contains a 7-way electrical plug to give you ample choices for your power-driven needs.
4 – Airline track tie-downs
More versatile tie-down points that are stronger throughout the entire hauling process.
Raised Side Rail with Aluminum Cap
CM’s durable and stylish aluminum side rail caps deliver a best-in-class, finished look, setting the industry standard for quality and appearance.
1/8” Aluminum Treadplate Deck
Our aluminum treadplate deck brings the corrosion resistance and look that users are looking for in an aluminum hauler.
Aluminum cast insert for LED rear lights and tag
CM uses cast aluminum housings, which won’t corrode like many of our competitors’ housings. When you choose an AL ER, you’re choosing a bed that performs better and looks better, longer.
Modular sealed wiring harness
Our modular sealed wiring harnesses are resistant to corrosion, deterioration and pulling apart, meaning they can withstand the harshest conditions.
7-way round and 5-way flat electrical plug standard on rear tailboard
This standard feature provides quality results and allows you to hook onto any trailer.
24,000 lb.-rated B&W bumper pull hitch
CM’s independently rated bumper pull hitch gives you best-in-class towing capacity, which is integrated into the entire frame.
3” steel roll-formed 3/16” channel cross members
These are the toughest, most durable cross members available on work trucks.
LED Stop, turn, tail, back up, and tag lights in skirt
CM’s lights are brighter and use less power than conventional incandescent lights, so your stops, turns, and tag lights will be easily seen and recognized.
Stainless fenders and aluminum tread plate trim
A durable and better-looking fender that will serve you well on the road. Our stainless fenders last longer and resist corrosion.
Angled fuel fill
This great-looking feature provides a no-corrosion zone for all your in-and-out hauls.
Specs and Features
Lengths 84", 8’6", 9’4", 11’4"
Headache Rack Aluminum Tube
Deck 1/8" Aluminum Treadplate
Frame Rails 4" Structural Channel Steel
Crossmembers 3” Aluminum Extruded Channel
Rear Skirt Solid One Piece with Rear Step
GN Hitch 30K B&W Hitch with Welded Ball
BP Hitch 24K lb. B&W Hitch with 2 ½” Receiver Tube
Side Rails Raised Side Rail with Aluminum Cap
Fuel Fill Angled (Cast Aluminum)
12V Trailer Plug 12V Round 7 Pin in GN Box, Round 7 Pin/4 Way Flat on Rear
Rear Lighting Clear LED Oval with Chrome Housing
Light Box (Rear Skirt) Cast Aluminum
Marker Lighting Bullet DOT Approved LED
Toolbox (4) Standard Integrated
Toolbox Handle Chrome T-Handle Compression
Fenders Chrome Radius
Sidesteps Aluminum steps in front of and behind fender
