2 – LED recessed tail, brake and backup lights mounted in headache rack
CM’s lights are brighter and use less power than conventional incandescent lights, so your stops, turns, and tag lights will be easily seen and recognized.
Integrated One Piece Aluminum Tube Headache Rack
Our headache racks are designed with the best and strongest materials, designed to set the standard when it comes to safety and protecting our customers.
30,000 lb.-rated B&W gooseneck hitch with 7-way electrical plug
This is a best-in-class, independently tested gooseneck hitch that handles even your toughest hauls. It also contains a 7-way electrical plug to give you ample choices for your power-driven needs.
4″ structural steel channel frame rails
Because we don’t use roll-formed runners, our structural 4″ channel frame rails are stronger and more durable than any on the market. They also prevent any rusting from the interior of the tube.
3/8” x 2” Aluminum Rub Rails & Stake Pockets
These side rails will help secure your toughest loads while providing multiple tie-down points throughout your hauling jobs.
3” Aluminum Extruded Channel
Realize the benefits of our lightweight, more corrosion resistant aluminum structure without any loss in strength.
Modular sealed wiring harness
Our modular sealed wiring harnesses are resistant to corrosion, deterioration and pulling apart, meaning they can withstand the harshest conditions.
7-way round and 5-way flat electrical plug standard on rear tailboard
This standard feature provides quality results and allows you to hook on to any trailer.
24,000 lb.-rated B&W bumper pull hitch
CM’s independently rated bumper pull hitch gives you best-in-class towing capacity, which is integrated into the entire frame.
Angled fuel fill
Provides a shinier, and better-looking feature to your work truck, as well as a no-corrosion zone for all your in-and-out hauls.
Our recessed tool box doors provide maximum safety in our large boxes to prevent weathering of your tools and equipment. For security, the dual latches lock with a key and padlock loop when desired.
* Beds designed for a RAM Mega Cab will only have two boxes in the rear to accommodate standards on this chassis.
Exclusive Feature:
2 – MegaBox toolboxes (one per side)
Store more with CM’s unique MegaBox toolboxes. At 54″ wide, with easy-access suicide doors, our MegaBox toolboxes hold all your essentials — and more! This feature is available only on 11’4″ models.
Specs and Features
Lengths 8'6", 9'4", 11'4"
Headache Rack Aluminum Tube
Deck Extruded Aluminum Floor
Frame Rails 4" Structural Channel Steel
Crossmembers 3” Aluminum Extruded Channel
Rear Skirt Solid One Piece with Rear Step
GN Hitch 30K B&W Hitch with Welded Ball
BP Hitch 24K B&W 2 ½” receiver hitch with receiver tube
Side Rails 3/8” x 2” Aluminum Extrusion w/Aluminum Stake Pockets
Fuel Fill Angled (Cast Aluminum)
12V Trailer Plug 12V Round 7 Pin in GN Box, Round 7 Pin/4 Way Flat on Rear
Rear Lighting Clear LED Oval
Light Box (Rear Skirt) Aluminum
Marker Lighting Bullet DOT Approved LED
Toolbox (2) Standard Integrated in Rear, (2) Tall Vertical Integrated in Front
Toolbox Handle Chrome T-Handle Compression
Toolboxes (Special Sizes) 11'4" Models include MEGABOX toolbox configuration
Fenders Aluminum Radius
Sidesteps Aluminum steps in front of and behind fender
